Lesson Plan: Ecommerce Engine
Unit
Network Systems
Duration
90-120 Minutes
Target Level
High School / Intro CS
Topic
Network Topology
Learning Objectives
Compare and contrast Star, Mesh, and Hybrid network topologies.
Analyze the specific infrastructure needs of an e-commerce business (uptime, scalability, security).
Design a network diagram that utilizes redundancy to prevent "Single Points of Failure."
Evaluate the trade-offs between cost, complexity, and reliability in network design.
Materials Needed
Ecommerce Engine Slides (Intro & Concepts)Topology Blueprint Worksheet (Guided Practice)Global Storefront Project Guide (Summative Assessment)Drawing tools (Digital like LucidChart or physical paper/markers)
Essential Question
"How does the physical and logical arrangement of a network determine the success or failure of a global online business?"
Instructional Sequence
01
The Hook: Black Friday Crisis (10 min)
Present a scenario where a major e-commerce site goes down during a peak sale. Ask students: "Why did it crash? Is it always the software, or could it be the physical path the data takes?" Use Slide 2-3 to drive this discussion.
Key Question: What happens to a business if their 'Buy Now' button stops working for just 60 seconds? (Amazon loses ~$220,000 every minute of downtime).
02
Topology Deep Dive (20 min)
Use the Ecommerce Engine Slides to cover Star, Mesh, and Hybrid topologies. Focus on the e-commerce context: Why would a warehouse use Star? Why does the Data Center need Mesh?
Star: Cheap, easy, but central failure point.Mesh: Reliable, redundant, but expensive and complex.Hybrid: The best of both worlds for growing businesses.
03
Guided Practice: The Blueprint (30 min)
Hand out the Topology Blueprint Worksheet . Students work through three mini-scenarios (The Warehouse, The HQ, The Server Farm) to decide which topology fits best based on a provided budget and reliability requirement.
04
Project Launch: The Global Store (40-60 min)
Introduce the Global Storefront Project . Students act as Lead Network Architects for "SwiftCart," a new global brand. They must design a complete network incorporating multiple topologies, justify their choices, and perform a "Stress Test" analysis.
Discussion Starters
"If you had an unlimited budget, would you ever not use a full Mesh topology? Why?"
"In an e-commerce setup, which is more dangerous: a slow network or a network that goes down once a week?"
"How does a Hybrid topology support a business as it grows from a garage to a global warehouse?"
Differentiation Strategies
Support (Scaffolding)
Provide pre-drawn icon cards (Server, PC, Router) for students to physically move around during the design phase. Use the 'Single Point of Failure' checklist for the project.
Challenge (Extension)
Introduce "Chaos Monkey" scenarios: 'Your main fiber line to the warehouse was cut by a backhoe. Does your e-commerce site still process orders?' Ask for specific backup pathing (Redundancy).
Teacher Pro-Tip
When students are designing their networks, encourage them to "break" their own designs. Ask them to point to any single cable or device. If the whole network stops working when that point is removed, they've found a bottleneck. In e-commerce, bottlenecks are lost revenue.
Ecommerce Engine Slides System Architecture
ECOMMERCE ENGINE
Building the Network Backbones of the Global Digital Economy
Topology Design
Module 4.2
The $200,000 Minute
When an e-commerce giant's network fails, it's not just a glitch. It's a financial catastrophe.
Amazon Downtime Cost
$220,000+
Per single minute of outage
"Sorry, our site is temporarily down."
The most expensive sentence in business.
Network Topology
The Topology of a network is the physical and logical arrangement of its components.
Physical: Where the wires go and where the hardware sits.
Logical: How the data actually flows through the paths.
Cost
Speed
Reliability
Scalability
The Star
Centralized Efficiency
Level 1: Basic
The Concept
All devices connect to a central hub or switch. If one cable fails, only that device disconnects.
Pros
Cheap & Simple
Easy to expand
Cons
Hub fails = Whole network fails
The Mesh
Maximum Redundancy
Level 3: Expert
The Concept
Every node is connected to every other node. Data can take multiple paths to reach its destination.
Pros
No single point of failure
High security
Cons
Insanely expensive
Massive cable mess
The Hybrid
The E-commerce Choice
The Warehouse
Uses Star Topology . Hundreds of handheld scanners connect to central access points. Speed and cost matter most here.
The Data Center
Uses Mesh Topology . Servers must never go offline. Every server connects to multiple switches and power sources.
Hybrid =
Combining different topologies to meet specific business needs and budget constraints.
Architect's Comparison
Topology Cost Reliability Best For...
Topology Blueprint Worksheet Topology Blueprint
Architect Practice Log // Unit 4.2
Architect:
Date:
Mission: As a Network Architect for "SwiftCart," you must design the infrastructure for three key locations. Choose the most appropriate topology (Star, Mesh, or Hybrid) based on the specific business needs and constraints.
01 The Local Warehouse
Budget: LOW // Devices: 50+
The warehouse uses 50 handheld scanners to track inventory. If one scanner's connection fails, it shouldn't affect the others. The budget is tight, and we need a setup that is easy to troubleshoot.
Recommended Topology:
Justification (Why?):
Sketch Diagram Here
02 The Data Fortress
Budget: HIGH // Reliability: CRITICAL
This server farm processes all credit card payments. If this network goes down for even one minute, the company loses $200k. There must be multiple paths for data to travel so that a single broken cable doesn't cause a blackout.
Recommended Topology:
Justification (Why?):
Sketch Diagram Here
Stress Test Analysis
Look at the diagram below of a typical Star Topology used in an office. Identify the critical weakness.
HUB
Office Network A
1. Define "Single Point of Failure" in your own words:
2. In Diagram A, what is the single point of failure? What happens if it breaks?
Terminology Check
Topology
A. A network where every node is connected to every other node.
Redundancy
B. The physical or logical layout of a network's components.
Full Mesh
C. Having duplicate components or paths to ensure availability.
Scalability
D. The ability of a network to grow as the business expands.
The CEO's Challenge
"I want a network that is 100% reliable (Mesh), but I only have $5,000 to build it for our 20-person headquarters. What compromise do you suggest?"
Global Storefront Project Guide Internal Project Brief
Global Storefront
Project
Project ID
SC-ARCH-2026
The Mission
SwiftCart is expanding from a local boutique to a global e-commerce power. As the Lead Network Architect , you must design the physical and logical backbone that connects our Global HQ, regional warehouses, and our critical server farm. Our success depends on your ability to balance cost, speed, and 100% uptime.
Requirements
Location 1: Global HQ (London)
Supports 100+ office staff. Must be easy to add new desks (Scalability) without high cable costs.
Location 2: Warehouses (NY & Tokyo)
High-speed Wi-Fi and scanner connectivity. If one hub fails, only that zone should be affected.
Location 3: The Vault (Data Center)
Stores all customer data and payments. Must have ZERO single points of failure. Cost is not an issue here.
Project Deliverables
1
Master Topology Map: A visual diagram showing how all components are connected.
2
Architecture Report: Justification for which topology was used at each location.
3
Redundancy Audit: A "What If" analysis explaining how the network survives a cable cut.
Architect's Sandbox
Drafting Area
Use this space to sketch your initial thoughts for the "Hybrid" connection between locations. How will the Warehouses connect to the Data Center? How does the HQ talk to them both?
Preliminary Sketch Area
Redundancy Level (1-10)
Estimated Budget Profile
Primary Growth Strategy
The Stress Test
In your final presentation, your teacher (the CEO) will choose one connection in your diagram to "disable." You must be able to show—on the spot—how the data reroutes to keep the business running.
Deadline
End of Period
Blueprint Answer Key Blueprint Answer Key
Teacher Resource // Topology Practice
Version
1.0 Final
01 The Local Warehouse
Recommended Topology
Star Topology
Key Justification
Low budget requirement and ease of troubleshooting. Since scanners operate independently, a central hub (Star) is efficient. A failure in one scanner cable won't affect others.
02 The Data Fortress
Recommended Topology
Full Mesh Topology
Key Justification
High reliability and redundancy are critical. Mesh ensures multiple data paths. Even with cable/node failures, the network stays up, protecting the $200k/minute revenue.
Stress Test Analysis
1. Definition of "Single Point of Failure"
Any part of a system that, if it fails, will stop the entire system from working. It represents a lack of redundancy.
2. Identification in Diagram A
The Central Hub/Switch. If the hub loses power or fails, every connected device loses connection simultaneously.
Terminology Check
Topology
B
Redundancy
C
Full Mesh
A
Scalability
D
The CEO's Challenge Answer
The best compromise is a Hybrid Topology . Use a Star Topology for the 20 staff PCs to keep costs low and wiring simple. Then, implement Mesh-like redundancy only for the backbone—using two internet service providers (ISPs) and redundant routers. This provides "critical reliability" where it counts most without the expense of mesh-wiring every individual desk.
Packet Relay Activity Guide Unplugged Simulation
Packet Relay Activity
Physical Networking & Topology Stress Test
Engage
Active Play
Materials
• Large ball of yarn/string
• Envelopes (The "Packets")
• Index cards (Role Tags)
• Scissors (The "Chaos Monkey")
Space Needed
Clear floor area or outdoor space (approx 15x15 ft)
Group Size
8–20 Students per network
The Concept
Students act as "Nodes" (Servers, Customers, Warehouses) in an e-commerce network. They will physically connect themselves using a "cable" (yarn) and attempt to pass "Order Packets" (envelopes) through the network while the teacher introduces "network failures."
Round 1: The Star (Efficient but Fragile)
1
Setup: One student is the "Central Switch." Everyone else stands in a circle around them. Every student holds one end of a yarn piece; the Switch holds the other ends of all pieces.
Goal: Move 5 "Orders" from a "Customer" to the "Server" (on the opposite side of the circle). Packets must go through the Switch.
The Hack: Mid-round, "cut" (or drop) the yarn connecting the Switch to the Server. What happens? (The entire system fails to deliver).
Round 2: The Mesh (Redundant but Complex)
2
Setup: Use multiple balls of yarn. Each node must connect to at least three other nodes. The floor should look like a spiderweb.
Goal: Move "Orders" through any available path. Nodes must signal to each other where the path is clear.
The Hack: The "Chaos Monkey" (teacher) walks around and cuts two random strings. Does the order still get through? (Usually, yes! Redundancy wins).
Post-Relay Debrief
Observation Prompts
The Physical Load
How did it feel to be the "Central Switch" in Round 1? Was it stressful? (Students often feel overwhelmed by the volume of packets passing through one point).
The Setup Time
How much longer did it take to build the Mesh network? Why would an e-commerce company hesitate to build a 100% Mesh network?
Vocabulary Reinforcement
Latency: Measure how long it took for a packet to go from hand to hand in the Mesh vs. the Star.
Collision: Did two packets hit the same hand at the same time? How was it handled?
