Cosmic Coordinates Art Worksheet
Coordinate Geometry Lab • All Four Quadrants Grades 5–8 Mystery Graph
Cosmic Coordinates ✦ Mystery Plot
Plot ordered pairs, connect points within each section, and decode the spacecraft!
Cadet:
Date:
Score:
Protocol Crawl along x-axis (horizontal) first, then fly along y-axis (vertical). Lift pencil at STOP.
I: (+, +) II: (−, +) III: (−, −) IV: (+, −)
A Fuselage & Fins 21 Points • Continuous
- (0, 9) 2. (1, 7) 3. (2, 5) 4. (2, 0) 5. (5, −3) 6. (6, −6) 7. (3, −5) 8. (2, −4) 9. (2, −6) 10. (1, −6) 11. (1, −7) 12. (−1, −7) 13. (−1, −6) 14. (−2, −6) 15. (−2, −4) 16. (−3, −5) 17. (−6, −6) 18. (−5, −3) 19. (−2, 0) 20. (−2, 5) 21. (−1, 7)
Connect 21 back to (0, 9): STOP
B Cockpit Porthole & Stripes Lift at STOP
Porthole: (0, 5) → (1, 4) → (1, 2) → (0, 1) → (−1, 2) → (−1, 4) → (0, 5) STOP
Stripe 1: (−1, 6) → (1, 6) STOP
Stripe 2: (−2, 2) → (2, 2) STOP
Stripe 3: (−2, −2) → (2, −2) STOP
C Thruster Exhaust Flames Flame Burst
Blast: (−1, −7) → (−2, −9) → (−1, −8) → (0, −10) → (1, −8) → (2, −9) → (1, −7) STOP
Inner Spike: (0, −7) → (0, −9) STOP
D Deep Space Stars 4 Quadrants
Star 1 (Quad II): (−5, 7)→(−5, 9) & (−6, 8)→(−4, 8) STOP
Star 2 (Quad I): (5, 7)→(5, 9) & (4, 8)→(6, 8) STOP
Star 3 (Quad III): (−8, −2)→(−8, 0) & (−9, −1)→(−7, −1) STOP
Star 4 (Quad IV): (8, −2)→(8, 0) & (7, −1)→(9, −1) STOP
Pre-Flight Telemetry Check
1. Right wingtip at (6, −6) is in:
Quadrant:
2. Highest tip of the rocket nose:
Point: ( ____ , ____ )
3. Lowest thruster flame (0, −10) is on:
Axis:
4. In Quad III, both signs are:
Signs: ( ____ , ____ )
Flight Deck
Coordinate Navigation Grid
Use a ruler to connect ordered pairs in each section. Lift pencil at STOP.
Cadet Name
Date
QUADRANT I (+, +) QUADRANT II (−, +) QUADRANT III (−, −) QUADRANT IV (+, −) x y 0 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 1 2 3 4 5 6 7 8 9 10 10 9 8 7 6 5 4 3 2 1 -1 -2 -3 -4 -5 -6 -7 -8 -9 -10
Mission Decoded: Identify the Mystery Object
The plotted mystery spacecraft is a: ________________________________
Coloring Palette: Fuselage (Silver/Blue) • Fins (Crimson) • Flames (Orange/Gold)
Pre-Launch Checklist
[ ] Section A Hull [ ] Section B Window [ ] Section C Flames [ ] Section D Stars
Verify coordinates with your mission wingman!
Cosmic Coordinates Answer Key
Educator Resource • Answer Key & Facilitation Guide Teacher Copy • Confirmed Solutions
Cosmic Coordinates ✦ Teacher Guide
Instructional notes, telemetry answers, common misconceptions, and scoring guide.
Mystery Object Identity Space Rocket / Apollo Shuttle
Page 1 Pre-Flight Telemetry Check — Complete Answer Key 4 Pts Total
1. Right Wingtip (6, −6) Quadrant:
Quadrant IV (+x = right, −y = down)
2. Highest Tip of Rocket Nose:
(0, 9) (Lies on positive y-axis)
3. Lowest Flame Spike (0, −10) Location:
y-axis (When x = 0, point is on the y-axis)
4. Quadrant III Sign Rule:
( − , − ) Both x and y are negative
Common Plotting Pitfalls & Diagnostic Fixes
X/Y Inversion Error
Students plot (2, 5) as 2 up and 5 right. Remedy: Remind cadets: "Walk in the hallway (x) before taking the elevator (y)!"
Zero on the Axis
Confusing (0, 9) with (9, 0). Clarify that 0 means zero horizontal movement from the center line.
Ignoring the STOP Rule
Connecting the wing to the window porthole. Emphasize that every STOP requires lifting the pencil completely.
Geometric Dimensions & Symmetry Audit
- • Line of Bilateral Symmetry: x = 0 (the y-axis)
- • Total Fuselage Height: 16 units (from y = 9 to y = −7)
- • Maximum Wing Span (Wingspan): 12 units (from x = −6 to x = 6)
- • Full Vehicle Height with Flame: 19 units (from (0, 9) to (0, −10))
Quadrant Point Audit
Quad I: 6 points
Quad II: 6 points
Quad III: 11 points
Quad IV: 11 points
Axes intercept points: (0, 9), (0, 5), (0, 1), (0, −10).
Differentiation & Extension Missions
Targeted Intervention: Provide colored highlighters: blue for positive coordinates, pink for negative coordinates. Have students annotate coordinates before placing dots on the plane.
Early Finisher Extension: Ask students to write coordinates for their own celestial body (e.g., a moon or orbiting alien probe) with vertices located strictly inside Quadrant II.
Visual Key
Master Plotted Solution
Completed rocket outline with all 4 quadrants, labels, and vertex markers.
