Window Pane Pattern Guide
Resized Throw Edition • 5 Fabrics
Window Pane Quilt
Original alternating pane layout scaled to generous throw size. Borderless with no middle stripe.
Finished Size
46¼″ × 57″
Target Size Achieved!
Rotary Cutting Plan (From 5 Half-Yards: A, B, C, D, E)
Standard ¼″ Seam Allowance Throughout
From EACH Fabric (A–E) 5 Half-Yards (18″ × 42″ WOF):
- • Cut (2) 9¾″ × 18″ rectangles
- • Cut (2) 9¾″ × 11½″ pane squares
- • (Total: 10 rectangles & 10 pane squares)
Dimension Breakdown How 46¼″ × 57″ is Created:
- • 5 columns × 9¼″ finished = 46¼″ wide
- • (2) 17½″ + (2) 11″ blocks = 57″ high
- • 100% borderless • No middle stripe
Finishing Requirements Supplies Needed:
- • Backing: 3 Yards (standard 42″–44″ joined)
- • Batting: 52″ × 63″
- • Binding: ½ Yard (or use cut leftovers)
Quilt Layout Diagram (46¼″ × 57″ • 5 Columns)
Flush Center Seam • Borderless Edge
Col 1
A 9¾″ × 11½″
B 9¾″ × 18″
C 9¾″ × 11½″
D 9¾″ × 18″
Col 2
C 9¾″ × 18″
D 9¾″ × 11½″
E 9¾″ × 18″
A 9¾″ × 11½″
Col 3
E 9¾″ × 11½″
A 9¾″ × 18″
B 9¾″ × 11½″
C 9¾″ × 18″
Col 4
B 9¾″ × 18″
E 9¾″ × 11½″
D 9¾″ × 18″
E 9¾″ × 11½″
Col 5
D 9¾″ × 11½″
E 9¾″ × 18″
A 9¾″ × 11½″
B 9¾″ × 18″
5 Fabric Panes: Fabric A Fabric B Fabric C Fabric D Fabric E
Page 1 of 2 • Assembly Steps on Page 2
Assembly & Construction Guide
Easy rotary cutting and column piecing for the 46¼″ × 57″ borderless quilt.
46¼″ × 57″ Target
How to Cut Each 18″ × 42″ Half-Yard (Identical for A, B, C, D, E)
Uses Standard Quilter's Ruler
Strip 1 (9¾″ × 18″) Full 18″ Rectangle
Strip 2 (9¾″ × 18″) Full 18″ Rectangle
Strip 3 (9¾″ × 11½″) Pane Square (6½″ scrap)
Strip 4 (9¾″ × 11½″) Pane Square (6½″ scrap)
Rem. ~3″
Along the 42″ width of fabric (WOF), cut (4) strips measuring 9¾″ wide. Leave the first two strips at their full 18″ length. Trim the other two strips down to 11½″ tall. Repeat for all 5 fabrics!
Step-by-Step Column Sewing & Assembly
Step 1: Sew Pane Sets
Follow the Page 1 diagram to stitch each column's upper set (one 9¾″×11½″ pane + one 9¾″×18″ rectangle) and lower set. Each pair measures 9¾″ wide × 29″ unfinished.
Step 2: Join Upper to Lower
Sew the upper set directly to the lower set for each column. No middle row or divider is needed. Press this center horizontal seam toward the 18″ rectangle to nest seams.
Step 3: Join the 5 Columns
Pin Columns 1 through 5 side-by-side, matching the center horizontal seams. Stitch using a ¼″ seam allowance. Press long vertical seams open flat. Quilt finishes at 46¼″ × 57″!
Piece Inventory by Fabric (10 Rectangles + 10 Panes Total)
Fabric A (2) 9¾″×18″
(2) 9¾″×11½″
Fabric B (2) 9¾″×18″
(2) 9¾″×11½″
Fabric C (2) 9¾″×18″
(2) 9¾″×11½″
Fabric D (2) 9¾″×18″
(2) 9¾″×11½″
Fabric E (2) 9¾″×18″
(2) 9¾″×11½″
Zero Waste Binding Tip: The leftover 6½″ × 9¾″ end scraps from your 5 fabrics can be cut into 2¼″ strips and joined for a delightful coordinating scrappy binding!
Exact 46¼″ × 57″ 📐
